Getting Started with 3D Printing
-
Product label:
PLA Ingeo 870 Filament
Eolas Prints
SKU: PLA-870-1.75M-BLK-1KG
Increments of 1
Minimum of 1
Maximum of
Low stock
In stock, ready to ship
Sale price
€30,50 EUR
-100%
Regular price
€0,00 EUR
Regular price
€30,50 EUR
Unit price
per
Tax included.
Shipping calculated at checkout.
PLA Ingeo 870 Filament
Sale price
€30,50 EUR
Regular price
€0,00 EUR
Regular price
€30,50 EUR
Unit price
per
Couldn't load pickup availability
Spain & Portugal (Mainland): Order before 4PM to receive it tomorrow. Except weekends.
Rest of the world: Express shipping options available at checkout.
EU VAT Exempt: No VAT on all EU B2B orders. Please contact us.
Spain: Electronic invoicing options available via FACe. Please contact us.
Spool dimensions
Our spools are compatible with all major 3D printer brands including Prusa, Bambu Lab (AMS & AMS Lite), Flashforge, and more. The standardised axle diameter ensures seamless integration with your existing equipment.
|
Specification |
1kg |
2kg |
5kg |
8kg |
10kg |
15kg |
20kg |
|---|---|---|---|---|---|---|---|
|
Outer Diameter (d1) |
200 mm |
300 mm |
350 mm |
335 mm |
335 mm |
335 mm |
335 mm |
|
Inner Diameter (d2) |
105 mm |
212 mm |
180 mm |
190 mm |
190 mm |
100 mm |
100 mm |
|
Hub Diameter (d3) |
52 mm |
52 mm |
52 mm |
51 mm |
51 mm |
31 mm |
31 mm |
|
Axle Diameter (d5) |
11 mm |
11 mm |
12 mm |
20 mm |
20 mm |
20 mm |
20 mm |
|
Flange Width (e1) |
44.5 mm |
44.5 mm |
44.5 mm |
70 mm |
70 mm |
70 mm |
70 mm |
|
Spool Length (l1) |
68 mm |
100 mm |
100 mm |
245 mm |
245 mm |
Variable |
Variable |
|
Winding Length (l2) |
59 mm |
90 mm |
90 mm |
220 mm |
220 mm |
Variable |
Variable |
|
Winding Volume |
1,342 cm³ |
3,220 cm³ |
6,366 cm³ |
13,147 cm³ |
6,366 cm³ |
— |
— |
|
Nominal Weight |
— |
600 gr |
600 gr |
1,050 gr |
1,050 gr |
— |
— |
Have a question?
Description
Eolas Prints PLA Ingeo 870 is a high-performance, high-impact PLA filament engineered for demanding applications. Based on NatureWorks Ingeo 870 resin, it combines the ease of printing of standard PLA with thermal resistance that rivals ABS — reaching over 85°C after a simple annealing process.
Key Properties
| Heat deflection temperature (annealed) | 85°C+ (after 15–20 min at 120°C) |
| Heat deflection temperature (unannealed) | ~55°C |
| Impact resistance | High — significantly tougher than standard PLA |
| Density | 1.24 g/cm³ |
| Shrinkage (annealing) | ~1–2% — design accordingly |
| Shrinkage (printing) | Low — excellent dimensional stability |
| Base resin | NatureWorks Ingeo 3D870 |
| Eco-friendly | Derived from renewable resources (corn starch / sugarcane) |
| Diameter tolerance | ±0.05 mm |
Recommended Print Settings
| Nozzle temperature | 195–220°C |
| Bed temperature | 0–50°C |
| Print speed | 40–80 mm/s |
| Cooling fan | 80–100% after first layer |
| Enclosure | Not required |
| Diameter tolerance | ±0.05 mm |
Annealing Process
Place finished prints on a flat surface in an oven at 120°C for 15–20 minutes. This controlled crystallisation raises the heat deflection temperature to over 85°C and increases impact resilience by approximately 15% compared to standard PLA. Allow to cool slowly inside the oven. Parts shrink approximately 1–2% during annealing — compensate by designing slightly oversized.
Recommended Applications
- Functional prototypes requiring heat resistance
- End-use parts exposed to elevated temperatures
- Mechanical components and fixtures
- Automotive interior parts
- Consumer products requiring durability and precision
Manufactured in Spain
Manufactured at Eolas Prints' facility in Cantabria, Spain, under ISO 9001 and ISO 14001 standards. Available in 1.75mm and 2.85mm in Black, White, and Grey.
Technical Datasheet
Download print profiles
Achieve superior 3D printing results with our custom print profiles, expertly calibrated for Eolas Prints filaments. These profiles are meticulously developed to ensure optimal performance, saving you time on configuration and testing. By using our dedicated print profiles, you can expect consistent quality and reliability with every print.
Bambu Studio
Prusa Slicer
Idea Maker
Ultimaker Cura
Shipping policy
When do you ship?
We ship daily from stock. Orders placed after 1PM and 4PM on Fridays are shipped on Monday.
| Spain & Portugal | Orders placed before 4PM CET are shipped the same day. |
| Rest of the world | Orders placed before 1PM CET are shipped the same day. |
How do you ship?
Shipping times and options are available at checkout.
| Spain & Portugal |
GLS: Next Business Day UPS: 1 - 2 Business Day |
| Rest of Europe |
UPS Standard: 2 - 5 Business Days UPS Worldwide Saver: 1 - 2 Business Days UPS Express: 1 - 2 Business Days (Before 2PM) |
| North America |
UPS Worldwide Saver: 1 - 2 Business Days UPS Express: 1 - 2 Business Days (Before 2PM) |
| South America |
UPS Worldwide Saver: 2 - 5 Business Days |
| Middle East |
UPS Worldwide Saver: 1 - 2 Business Days UPS Express: 1 - 2 Business Days (Before 2PM) |
| Asia |
UPS Worldwide Saver: 5 - 7 Business Days |
| Australia & New Zealand |
UPS Worldwide Saver: 5 - 7 Business Days UPS Express: 3 - 5 Business Days (Before 2PM) |
How about Taxes & Duties?
| Taxes and custom duties are included only for EU countries. For rest of the world, UPS our logistics provider will get in touch with you pay any import duties or taxes based on your destination country. |
Our Guarantee
Specifications
Material
Polylactic Acid bio-polymer
Density
1.22 g/cm3
Hardness
Features
Easy to print, Mechanical properties similar to ABS, Alternative to styrene based materials.
Heat deflection temperature - HDT
ASTME2092: 75 - 85 °C (66 psi - 0.45 MPa)
Vicat softening temperature
N/A
Print temperature
195 - 230 °C
Bed temperature
0 - 70 °C
Print speed
40 - 100 mm/s
Nozzle
0.15 - 1.2 mm
Cooling
0 - 100 %
Chamber
Not Mandatory
Dry box
Not mandatory
Adhesive
Not mandatory (Use one for increased adhesion)
Diameter tolerance
± 0.05 mm
Compatibility
FDM (Fused Deposit Modelling) & FFF (Fused Filament Fabrication)
